Description
| CMRR | ≥ 100dB, with AC Filter | Calibrating voltage | 1mV± 3% |
| Input circuit | Floating | Voltage tolerance | ± 500mV |
| Input circuit current | ≤ 0.1µ A | Time constant | > 3.2s |
| Resolution | 12bit/1000Hz | Frequent response | 0.05Hz~150Hz |
| Operation mode | Manual/Auto | Noise level | ≤ 15µ Vp-p |
| Filter | AC. EMG Filter | Threshold | ≤ 20µ V |
| Drift filter | Anti-Drift System | Paper speed | 12.5, 25, 50mm/s (± 3%) |
| Input Impedance | > 50MΩ | Sensitivity | 5，10，20mm/mV |
| Patient current leakage |
< 10µ A |
Recorder |
High resolution thermal printer |
|
Specification of fuse |
T1.6A 250V Ø5×20 |
Battery |
Built-in rechargeable Li-ion battery 14.8V(4000mAh) |
|
Recording paper |
Thermal recording paper |
Package |
365mm×306mm×109mm |
- Modern in design, light in weight, compact in
- Simultaneously acquisition of 12 lead, full screen display of 12 channel ECG
- 2” color touch-screen, both push-button and touchoperation.
- Sensitive filters of ADS, HUM, and
- Automatic measurement, calculation, analysis, waveform Auto-analyze and auto-diagnostic can reduce doctor’s burden and improve workingefficiency.
- Automatic adjustment of baseline for optimal
- Thermal printer with 216mm print paper, synchronization print. It is high resolution thermo sensitive printer and thermal-array (8 dots/mm), you should not adjust anything Frequency Response is up to
- Lead off & lack off paper detection
- Built-in rechargeable li-ion battery (14.8V/4400mAh), AC/DC power
- Adapt to 100-240V, 50/60Hz AC powersupply
- Historical data and patient’s information can be reviewed and
- Support USB flash disk & SD memory, stored reports can be saved, opened, analyzed in PC via ECG playback software.
- The machine can store over 500 ECG reports in its built-in
- Standard RS232 and USB communication
- Connectwith PC via ECG workstation
- Sleepmode to save energy and extend LCD life
- The device can record real time clear and exact 12 channel ECG waveform and remark continually. The remark includes: lead sign, sensitivity, paper speed, filter state,
- Portable design with hidden handle, convenient to
- 7 level printing thick can be
